Dây Cáp Seoul Electric Cable - SEC/ Korea - Tổng Kho

Seoul Electric Cable – SEC /Korea: Cáp năng lượng tái tạo: Dây PV, UW-3PN, MV-105, FR CNCO-W, Cáp URD

Cáp mạng 5G: Cáp giáp khóa liên động bằng nhôm, Cáp quang học tổng hợp bằng nhôm liên khóa, Cáp quang, cáp Lan

AIA-90, AIAV-90, AIAO-90 / AIAO-HFCO / AIAO-O/F / AIAO-OPHF-CO / AIAV(O)-UTP / SINGLE ARMOR LOOSE TUBE CABLE / LOOSE TUBE CABLE / LOOSE TUBE CABLE (S-S) / ADSS CABLE / ADSS ( DOUBLE JACKET ) / MICRO DUCT CABLE / MICRO MODULE CABLE / DROP CABLE ( ROUND/FLAT ) / F-8 DROP CABLE / DISTRIBUTION CABLE / INTERLOCKING ARMOURED CABLE / BREAKOUT CABLE / LOOSE TUBE FLAT DROP CABLE / SIMPLEX / DUPLEX CORD / Optical fiber composite Coppe… / Optical fiber composite Power… / TONEABLE DROP CABLE / UTP 5E ( 2P, 4P ) / UTP 5E ( 25P ~ 100P ) / UTP 6 ( 2P, 4P ) / OUTDOOR UTP CAT 5E / OUTDOOR UTP CAT 5E S-S

Dây cáp điện: Nhà máy sản xuất, Lĩnh vực phân phối điện, Cầu trục,
Lĩnh vực khai thác, cáp công nghiệp, v.v.
Cáp Polyolefin chống cháy không cháy 22,9kV Halogen
Cáp điện loại trung tính đồng tâm, Cáp điện chống cháy dạng cây nước Cáp chống cháy & chống cháy / chịu nhiệt Cáp bọc giáp 35kV Cáp điện cách điện bằng polyethylene liên kết chéo

0,6 / 1kV CU / XLPE / PVC, AL / XLPE / PVC ; 300 / 300V dây vinyl ; 1.8 / 3kV CU / XLPE / PVC, AL / XLPE / PVC ; 300 / 500V dây vinyl ; 3.6 / 6kV CU / XLPE / PVC, AL / XLPE / PVC ; 300 / 500V dây cao su ; 6 / 10kV CU / XLPE / PVC, AL / XLPE / PVC ; 8,7 / 15kV CU / XLPE / PVC, AL / XLPE / PVC ; 12 / 20kV CU / XLPE / PVC, AL / XLPE / PVC ; 18 / 30kV CU / XLPE / PVC, AL / XLPE / PVC ; 15kV URD ; 25 kV URD ; 35kV URD ; 450 / 750V 60227 KS IEC 01 ; 300 / 500V 60227 KS IEC 07, 60227 KS IEC 06, 60227 KS IEC 08 ; 450 / 750V 60227 KS IEC 02 ; 0,6 / 1KV VCT ; 0,6 / 1kV PNCT ; Cáp hàn ; 0,6 / 1kV VV ; CV 0,6 / 1kV ; 0,6 / 1KV CV / AL ; 22,9KV-y FR CNCO-W / AL, TRCNCE-W / AL ; 0,6 / 1kV CVV-SB ; 0,6 / 1kV CVV-S ; 0,6 / 1kV TFR-CV ; 0,6 / 1kV TFR-GV ; 6/10kV TFR-CV ; 0.6/1kV TFR-CVV ; 0.6/1kV TFR-CVV-S ; 0.6/1kV TFR-CVV-SB ; 0.6/1kV TFR-8 ; 0.6/1kV TFR-3 ; 0.6/1kV HFCO ; THW, USE-2, THWN, THHN, WP, 8KV & 15KV & 25KV DBE ; 6/10kV HFCO ; 0.6/1kV HFCCO ; 0.6/1kV NFR-8 ; 0.6/1kV NFR-3 ; WOH-S ; ACSR

Cáp hạt nhân: Cáp nguồn, điều khiển, thiết bị đo (tín hiệu) cho nhà máy điện hạt nhân.
Cáp điện áp cao (5kV, 15kV), Thấp (600V) Cáp điều khiển (600V) Cáp điều khiển / thiết bị đo lường 600V XHHW Tuổi thọ Cáp điều khiển trong 60 năm

5kV, 15kV FR-EPR/CR, FR-EPR/CSP
600V FR-EPR/CR, FR-EPR/CSP
600V FR-EPR/CR, FR-EPR/CSP

Cáp trên tàu, giàn khoan, khí gas: Nội thất / bên ngoài tàu hoặc tàu Điện, Điều khiển, Thiết bị đo (Tín hiệu), Cáp thông tin liên lạc, Cấu trúc hàng hải & Nền tảng ngoài khơi, v.v.
Cáp JIS Cáp HF (không có Halogen) Cáp NEK606

3.6/6kV SPYCB ; 0.6/1kV SPYC ; 0.6/1kV DPY ; 0.6/1KV TPY ; 0.6/1kV FPY ; 0.6/1kV 5PY ; 0.6/1kV 6PY ; 0.6/1kV DPYC ; 0.6/1kV TPYE ; 0.6/1kV FPYE ; 0.6/1kV DPYCSLA ; 0.6/1kV TPYCSLA ; 0.6/1kV FR-SPYC ; 0.6/1kV FR-DPY ; 0.6/1kV FR-TPY ; 0.6/1kV FR-FPY ; 0.6/1kV FR-DPYE ; 0.6/1kV FR-TPYE ; 0.6/1kV FR-FPYE ; 150/250V MPY ; 150/250V MPYE ; 150/250V MPYCSLA ; 150/250V MPYC-S ; 150/250V FR-MPY ; 150/250V FR-MPYE ; 150/250V FR-MPYCSLA ; 150/250V TTY ; 150/250V TTYCSLA ; 150/250V TTYC-SLA ; 150/250V FR-TTPY ; 150/250V FR-TTPYCSLA ; 150/250V FR-TTPYC-SLA ; 0.6/1kV DPNP ; 0.6/1kV SCP ; 0.6/1kV SYP ; 0.6/1kV HF-CXO ; 0.6/1kV HF-CXOSA ; 0.6/1kV FRHF-CXO ; 0.6/1kV FRHF-CXOSA ; 150/250V(300V) HF-IXOSA ; 150/250V(300V) HF-IXO(i)SA ; 150/250V(300V) FRHF-IXOSA ; 150/250V(300V) FRHF-IXO(i)SA ; 0.6/1kV HFF-CX ; 3.6/6(7.2)kV, 6/10(12)kV, 8.7/15(17.5)kV HF-CXOSA ; VFD(EMC) HF-CXOSA ; High Voltage RFOU, RFCU ; Low voltage RFOU, RFCU ; Low voltage RU ; Low voltage BU ; Low voltage BFOU, BFCU ; Low voltage RX, UX ; Low voltage RFOU/VFD ; 250V RFOU, RFCU ; 250V RFOU(C), RFCU(C) ; 250V RFOU(I), RFCU(I) ; 250V RFOU(C), RFCU(C)-2 ; 250V RFOU(I/C), RFCU(I/C) ; 250V BFOU, BFCU ; 250V BFOU(C), BFCU(C)

Cáp Điều Khiển Ngoài Khơi (Offshore) SEC/ KOREA 250V RFOU(I), RFCU(I) | Chính Hãng – Giá Tốt Nhất

250V Instrumentation/control cable RFOU(I), RFCU(I)

Hãng Sản Xuất: Seoul Electric Cable – SEC /Korea
Xuất Xứ: KOREA

Halogen-free and/or Mud resistant cables for offshore installations
Multi-pair,(HF-)EPR insulated, Individual screen, Halogen free Inner covering /Bedding, Braid armour, Halogen free SHF2 or SHF MUD Resistance Instrumentation/control cables(Flame retardant) RFOU(I), RFCU(I)
Conductor: Tinned annealed copper wire according to IEC 60228 Class 2 or Class 5
Insulation: HF EPR as per IEC 60092-360(351), thickness as per IEC 60092-376
Individual screen: Screened by copper or aluminium backed polyester tape with tinned copper drain wire
Twisiting: Two/Three insulated cores shall be twisted together to form a pair/triad
Inner covering: Halogen free thermoset compound, thickness according to IEC 60092-376
Braid armour: Tinned copper wire braid (O), Galvanized steel wire braid (C)
Outer sheath: Halogen free thermoset compound SHF2 or halogen free MUD resistant thermoset compound SHF MUD complying with IEC 60092-360(359) and / or NEK 606.
Rated Voltage ：250V
Operating temperature ：-40 to 90℃

Marking
e.g. :S.E.C. 250V S1/S5 RFOU(I)-M 2 X 2 X 0.75SQMM NEK 606 IEC 60332-3A MUD SEOUL Year Length
e.g. :S.E.C. 250V S1/S5 RFCU(I)-M 2 X 2 X 0.75SQMM NEK 606 IEC 60332-3A MUD SEOUL Year Length

Cáp Điều Khiển Ngoài Khơi (Offshore) SEC/ KOREA 250V RFOU(C)-2, RFCU(C)-2 | Chính Hãng – Giá Tốt Nhất

250V Instrumentation/control cable RFOU(C)-2, RFCU(C)-2

Hãng Sản Xuất: Seoul Electric Cable – SEC /Korea
Xuất Xứ: KOREA

Halogen-free and/or Mud resistant cables for offshore installations
Multi-pair,(HF-)EPR insulated, Collective screen, Halogen free Inner covering/Bedding, Braid armour, Halogen free SHF2 or SHF MUD Resistance Instrumentation/control cables(Flame retardant) RFOU(C), RFCU(C)
Conductor: Tinned annealed copper wire according to IEC 60228 Class 2 or Class 5
Insulation: HF EPR as per IEC 60092-360(351), thickness as per IEC 60092-376
Twisiting: Two/Three insulated cores shall be twisted together to form a pair/triad
Collective screen: Screened by copper or aluminium backed polyester tape with tinned copper drain wire
Inner covering/Bedding: Halogen free thermoset compound, thickness according to IEC 60092-376
Braid armour: Tinned copper wire braid (O), Galvanized steel wire braid (C)
Outer sheath: Halogen free thermoset compound SHF2 or halogen free MUD resistant thermoset compound SHF MUD complying with IEC 60092-360(359) and / or NEK 60
Rated Voltage ：250V
Operating temperature ：-40 to 90℃

Marking
e.g. : S.E.C. 250V S2/S6 RFOU(C)-M 2 X 2 X 0.75SQMM NEK 606 IEC 60332-3A MUD SEOUL Year Length

e.g. : S.E.C. 250V S2/S6 RFCU(C)-M 2 X 2 X 0.75SQMM NEK 606 IEC 60332-3A MUD SEOUL Year Length

Cáp Điều Khiển Ngoài Khơi (Offshore) SEC/ KOREA 250V RFOU(I/C), RFCU(I/C) | Chính Hãng – Giá Tốt Nhất

250V Instrumentation/control cable RFOU(I/C), RFCU(I/C)

Hãng Sản Xuất: Seoul Electric Cable – SEC /Korea
Xuất Xứ: KOREA

Halogen-free and/or Mud resistant cables for offshore installations
Multi-pair, (HF-)EPR insulated, Individual and Collective screen, Halogen free Inner covering /Bedding, Braid armour,
Halogen free SHF2 or SHF MUD Resistance Instrumentation/control cables(Flame retardant) RFOU(I/C), RFCU(I/C)
Conductor: Tinned annealed copper wire according to IEC 60228 Class 2 or Class 5
Insulation: HF EPR as per IEC 60092-360(351), thickness as per IEC 60092-376
Individual screen: Screened by copper or aluminium backed polyester tape with tinned copper drain wire
Twisiting: Two/Three insulated cores shall be twisted together to form a pair/triad
Collective screen: Screened by copper or aluminium backed polyester tape with tinned copper drain wire
Inner covering/Bedding: Halogen free thermoset compound, thickness according to IEC 60092-376
Braid armour: Tinned copper wire braid (O), Galvanized steel wire braid (C)
Outer sheath: Halogen free thermoset compound SHF2 or halogen free MUD resistant thermoset compound SHF MUD complying with IEC 60092-360(359) and / or NEK 606
Rated Voltage ：250V
Operating temperature ：-40 to 90℃

Marking
e.g. :S.E.C. 250V RFOU(I/C)-M 2 X 2 X 0.75SQMM NEK 606 IEC 60332-3A MUD SEOUL Year Length
e.g. :S.E.C. 250V RFCU(I/C)-M 2 X 2 X 0.75SQMM NEK 606 IEC 60332-3A MUD SEOUL Year Length

Cáp Điều Khiển Ngoài Khơi (Offshore) SEC/ KOREA 250V BFOU, BFCU | Chính Hãng – Giá Tốt Nhất

250V Instrumentation/control cable BFOU, BFCU

Hãng Sản Xuất: Seoul Electric Cable – SEC /Korea
Xuất Xứ: KOREA

Halogen-free and/or Mud resistant cables for offshore installations
Multi-core, Mica tape, (HF-) EPR insulated, Halogen free Inner covering/Bedding, Braid armour, Halogen free
SHF2 or SHF MUD Resistance Instrumentation/control cables(Flame and Fire resistant) BFOU, BFCU
Conductor: Tinned annealed copper wire according to IEC 60228 Class 2 or Class 5
Fire proof layer: Mica / Glass tape
Insulation: HF EPR as per IEC 60092-360(351), thickness as per IEC 60092-376
Inner covering/Bedding: Halogen free thermoset compound, thickness according to IEC 60092-376
Braid armour: Tinned copper wire braid (O), Galvanized steel wire braid (C)
Outer sheath: Halogen free thermoset compound SHF2 or halogen free MUD resistant thermoset compound SHF MUD complying with IEC 60092-360(359) and / or NEK 606.
Rated Voltage ：250V
Operating temperature ：-40 to 90℃

Marking
e.g. : S.E.C. 250V BFOU-M 2 X 0.75SQMM NEK 606 IEC 60332-3A IEC 60331 MUD SEOUL Year Length
e.g. : S.E.C. 250V BFCU-M 2 X 0.75SQMM NEK 606 IEC 60332-3A IEC 60331 MUD SEOUL Year Length

Cáp Điều Khiển Ngoài Khơi (Offshore) SEC/ KOREA 250V BFOU(C), BFCU(C) | Chính Hãng – Giá Tốt Nhất

250V Instrumentation/control cable BFOU(C), BFCU(C)

Hãng Sản Xuất: Seoul Electric Cable – SEC /Korea
Xuất Xứ: KOREA

Halogen-free and/or Mud resistant cables for offshore installations
Multi-core, Mica tape,(HF-) EPR insulated, Collective screen, Halogen free Inner covering/Bedding, Braid armour, Halogen free
SHF2 or SHF MUD Resistance Instrumentation/control cables(Flame and Fire resistant) BFOU(C), BFCU(C)
Conductor: Tinned annealed copper wire according to IEC 60228 Class 2 or Class 5
Fire proof layer: Mica / Glass tape
Insulation: HF EPR as per IEC 60092-360(351), thickness as per IEC 60092-376
Inner covering: Halogen free thermoset compound, thickness according to IEC 60092-376
Collective screen: Screened by copper or aluminium backed polyester tape with tinned copper drain wire
Braid armour: Tinned copper wire braid (O), Galvanized steel wire braid (C)
Outer sheath: Halogen free thermoset compound SHF2 or halogen free MUD resistant thermoset compound SHF MUD complying with IEC 60092-360(359) and / or NEK 606.
NEK 606
IEC 60092-350
IEC 60092-352
IEC 60092-376
IEC 60092-360(351, 359)
IEC 60331 : Thử nghiệm chống cháy
IEC 60332-1 : Chống cháy
IEC 60332-3-22 Cat.A : Chống cháy
IEC 60684-2 : Kiểm tra hàm lượng Flo
IEC 60754-1 : Kiểm tra phát thải khí halogen
IEC 60754-2 : Kiểm tra độ pH và độ dẫn điện
IEC 61034-1,2 : Kiểm tra phát thải khói
UL 1581 : Khả năng chống tia cực tím (chống nắng)
CSA C 22.2 No.0.3 : Thử nghiệm uốn nguội (ở -40℃) và thử nghiệm va đập nguội (ở -35℃) ở nhiệt độ thấp (tùy chọn)

Marking
e.g. : S.E.C. 250V S4/S8 BFOU(C)-M 2C X 0.75SQMM NEK 606 IEC 60332-3A IEC 60331 MUD SEOUL Year Length
e.g. : S.E.C. 250V S4/S8 BFCU(C)-M 2C X 0.75SQMM NEK 606 IEC 60332-3A IEC 60331 MUD SEOUL Year Length
